Detay
DONANIM ÖZELLİKLERİ
Priz Tipi EU, UK, US, AR
Standartlar ve Protokoller HomePlug AV, IEEE802.3, IEEE802.3u, IEEE802.11b/g/n
Arabirim 2*10/100Mbps Ethernet Port
Buton Pair, Reset, Wi-Fi/Wi-Fi Clone
Güç Tüketimi Maximum: 7.608W (220V/50Hz)
Typical: 7.216W (220V/50Hz)
Standby: 4.610W (220V/50Hz)
LED Göstergesi PWR, PLC, ETH, Wi-Fi/Wi-Fi Clone
Boyutlar ( W X D X H ) TL-WPA4220: 2.1 x 1.6 x 3.7 in. (54 × 40 × 94 mm)
TL-PA4010: 2.0 × 1.1 × 2.6 in. (52 × 28.5 × 65 mm)
Menzil 300 Meters over electrical circuit
KABLOSUZ ÖZELLİKLERİ
Frekans 2.4-2.4835GHz
Bağlantı Hızı 11n: Up to 300Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Alıcı Hassasiyeti 270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Kablosuz Güvenlik 64/128-bit WEP / WPA / WPA2,WPA-PSK / WPA2-PSK
Gelişmiş Fonksiyonlar Enable/DisableWireless Radio,WMM, Wireless Statistics
İletim Gücü CE:<20dBm(2.4GHz)
FCC:<30dBm
YAZILIM ÖZELLİKLERİ
Modülasyon Teknolojisi OFDM (PLC)
Şifreleme Powerline Security:
128-bit AES
Wireless Security:
WEP, WPA/WPA2, WPA-PSK/WPA2-PSK Encryption
DİĞERLERİ
Sertifika CE, FCC, RoHS
Paket İçeriği Powerline Ethernet Adapter TL-WPA4220 & TL-PA4010
6.5 ft. (2 m) Ethernet cable (RJ45)
Resource CD
Quick Installation Guide
Sistem Gereksinimleri Windows 2000/XP/2003/Vista, Windows 7/8, Mac, Linux
Ortam Operating Temperature: 0°C~40°C (32°F ~104°F)
Storage Temperature: -40°C~70°C (-40°F ~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
